MES P Series(25W) 설명
● DC - DC CONVERTER
● ON - BOARD TYPE SMPS
● WIDE INPUT RANGE
● PROTECTION ( O.V.P / O.C.P / S.C.P)
● THERMAL SHUTDOWN
● ISOLATED OUTPUT
MES P Series(25W) 에 총 7개 제품이 등록되어 있습니다.
| MODEL NUMBER | INPUT(V) | OUTPUT(V) | MODEL TYPE | MODEL SIZE | CATALOGUE | DATA SHEET |
|---|---|---|---|---|---|---|
MES0550P
|
120 ~ 375 VDC | 5V / 5.0A | Single | 46 X 36.5 X H27 (mm) |  |
|
MES1220P
|
120 ~ 375 VDC | 12V / 2.0A | Single | 46 X 36.5 X H27 (mm) | |
|
MES1318P
|
120 ~ 375 VDC | 13V / 1.8A | Single | 46 X 36.5 X H27 (mm) | |
|
MES1515P
|
120 ~ 375 VDC | 15V / 1.5A | Single | 46 X 36.5 X H27 (mm) | |
|
MES1813P
|
120 ~ 375 VDC | 18V / 1.3A | Single | 46 X 36.5 X H27 (mm) | |
|
MES2410P
|
120 ~ 375 VDC | 24V / 1.0A | Single | 46 X 36.5 X H27 (mm) | |
|
MES0512MP
|
120 ~ 375 VDC | 5V/3.0A, 12V/0.4A | dual | 46 X 36.5 X H27 (mm) | |
