PA-SH Series Explanation
● AC - DC CONVERTER
● ON - BOARD TYPE SMPS
● WIDE INPUT RANGE
● PROTECTION ( O.V.P / O.C.P / S.C.P)
● THERMAL SHUTDOWN
● NO LOAD POWER CONSUMPTION <0.1~0.2W
● ISOLATED OUTPUT
● SMALL MULTI-PURPOSE POWER SUPPLY
There are 10 products in the PA-SH Series
| MODEL NUMBER | INPUT(V) | OUTPUT(V) | MODEL TYPE | MODEL SIZE | CATALOGUE | DATA SHEET |
|---|---|---|---|---|---|---|
PA0405SH
|
85 ~ 265 VAC | 5V / 0.7A | Single | 32 X 21 X H16.5 (mm) |  |
|
PA0412SH
|
85 ~ 265 VAC | 12V / 0.35A | Single | 32 X 21 X H16.5 (mm) | |
|
PA0415SH
|
85 ~ 265 VAC | 15V / 0.27A | Single | 32 X 21 X H16.5 (mm) | |
|
PA0424SH
|
85 ~ 265 VAC | 24V / 0.16A | Single | 32 X 21 X H16.5 (mm) | |
|
PA1005SH
|
85 ~ 265 VAC | 5V / 2A | Single | 43 X 24 X H20.5 (mm) | |
|
PA1012SH
|
85 ~ 265 VAC | 12V / 0.8A | Single | 43 X 24 X H20.5 (mm) | |
|
PA1015SH
|
85 ~ 265 VAC | 15V / 0.65A | Single | 43 X 24 X H20.5 (mm) | |
|
PA2012SH
|
85 ~ 265 VAC | 12V / 1.6A | Single | 50 X 27 X H23.5 (mm) | |
|
PA2015SH
|
85 ~ 265 VAC | 15V / 1.3A | Single | 50 X 27 X H23.5 (mm) | |
|
PA2024SH
|
85 ~ 265 VAC | 24V / 0.85A | Single | 50 X 27 X H23.5 (mm) | |
